LED Dimming & Driver Guide

A Practical Explanation for Designers, Consultants & Clients

Modern lighting is not just about choosing the fixture the driver and dimming method define performance, comfort, and reliability.

This guide explains LED drivers and dimming types in a simple, practical way.

1. What Is an LED Driver?

An LED driver converts mains power (220–240V AC) into a controlled output suitable for LEDs.

It also controls brightness, stability, flicker, and lifespan.

There are two main types of LED drivers:

• Constant Current (CC)

• Constant Voltage (CV)


Choosing the wrong type can lead to flicker, poor dimming, or LED failure.

2. Constant Current (CC) Drivers

What Is a Constant Current Driver?

A CC driver supplies a fixed current while automatically adjusting voltage based on the LED load.

Typical Applications

• COB downlights

• Spotlights & track lights

• Wall washers

• High-power linear architectural lights

• Façade & outdoor luminaires


Key Specifications (CC Drivers)

• Output Current:Common values: 350mA, 500mA, 700mA, 900mA, 1050mA


• Output Voltage Range: Example: 25–42V DC


• Power Rating: Example: 30W, 40W, 60W


• Dimming Support: DALI / 0–10V / Phase dimming / PWM (model dependent)


• Protection: Short-circuit, overload, thermal protection


Advantages

• Precise light output

• Excellent dimming stability

• Longer LED lifespan

• Ideal for professional & architectural lighting


Important:
The driver current must match the LED exactly. Over-current will damage the LED.

3. Constant Voltage (CV) Drivers

What Is a Constant Voltage Driver?

A CV driver delivers a fixed voltage (typically 12V or 24V), and the LED load controls the current.

Typical Applications

• LED strip lights

• Cove lighting

• Flexible linear lighting

• RGB / RGBW tape lighting


Key Specifications (CV Drivers)

• Output Voltage: 12V DC or 24V DC


• Maximum Power: Example: 100W, 200W, 300W


• Connection Type: Parallel wiring


• Dimming Support: 0–10V / DALI / PWM / Phase dimming


• IP Rating: IP20 (indoor), IP65 / IP67 (outdoor)


Advantages

• Simple installation

• Flexible layout

• Ideal for decorative lighting


Important:
Never mix 12V LEDs with 24V drivers (or vice versa).

4. LED Dimming Methods Explained

Phase Dimming (TRIAC)

Leading Edge (Forward Phase)

• Cuts the front part of the AC waveform

• Older technology


Pros

• Widely available

• Low cost


Cons

• Flicker at low levels

• Audible buzzing

• Limited LED compatibility


Trailing Edge (Reverse Phase)

• Cuts the end part of the AC waveform

• Designed for LEDs


Pros

• Smooth dimming

• Quiet operation

• Better low-level control


Cons

• Requires compatible driver

• Slightly higher cost


0–10V Dimming

A separate low-voltage control signal controls brightness.

• 10V = 100% brightness

• 0V = minimum level or OFF


Key Points

• Requires two additional control wires

• Analog control system


Pros

• Flicker-free

• Reliable and stable

• Common in commercial projects


Cons

• No individual addressing

• Limited automation features


DALI (Digital Addressable Lighting Interface)

A digital lighting control system designed for professional projects.

Key Features

• Each driver has a unique address

• Grouping, scenes, scheduling

• Two-wire, polarity-free control bus

• Feedback & monitoring


Pros

• Highly flexible

• Ideal for offices, hotels, malls, villas

• Scalable and future-proof


Cons

• Higher initial cost

• Requires programming & commissioning


PWM (Pulse Width Modulation)

Controls brightness by rapidly switching LEDs ON and OFF.

Commonly Used In

• CV LED strips

• RGB / RGBW controllers

• DMX lighting systems


Pros

• Excellent low-level dimming

• No color shift


Cons

• Poor-quality PWM can cause flicker

• Frequency must be properly designed
